How does a microwave oven heat food without a flame?
It started with a melted candy bar in the pocket of a radar engineer, and an egg that exploded in a colleague's face.
▶ Start the storyA microwave oven heats food by making its molecules spin. Inside the box, a stream of microwaves, a kind of electromagnetic radiation, sets up an electric field that flips back and forth billions of times a second. Water, fats and many other molecules in food are lopsided, slightly positive at one end and slightly negative at the other, so they keep twisting to line up with the field. All that twisting turns into heat. This is called dielectric heating.
Step 1: Microwaves fill the box
About 2.45 GHz, a 12.2 cm wavelength
Step 2: The field keeps reversing
Lopsided molecules like water and fats rotate to follow it
Step 3: Rotation becomes heat
In roughly the outer centimetre of the food
Step 4: Heat spreads inward
The centre warms by ordinary conduction
Household ovens use microwaves of about 2.45 gigahertz, with a wavelength of 12.2 centimetres. Despite the popular idea, food does not cook from the inside out: the microwaves only reach about a centimetre into most foods, and the middle of a thick dish warms up as heat creeps inward from that outer layer. That's why a big plate of leftovers can be scalding at the edge and cold in the centre.
The invention began with an accident. Percy Spencer, an engineer at the American company Raytheon, noticed that the microwaves from a radar set he was working on had started to melt a candy bar in his pocket. He tried popcorn next, then an egg, which exploded in a colleague's face. In 1947 Raytheon sold the first commercial microwave oven, the Radarange, a machine almost 1.8 metres tall.
Quiz me
0/3
Recap
Microwaves spin the molecules in the outer centimetre of food; the rest is heated by ordinary conduction.
Surprising fact · The oven was invented after microwaves from a radar set melted a candy bar in engineer Percy Spencer's pocket.
