How did a sphere make the Sydney Opera House possible?
Nobody knew how to build the famous sails until the design team realised they could all be cut from one giant ball.
▶ Start the storyThe Sydney Opera House's famous white sails could only be built once its designers found a piece of simple geometry: every shell is cut from the surface of the same sphere, a ball 75.2 metres in radius.
When the Danish architect Jørn Utzon won the design competition in 1957, his sails were just beautiful, free-flowing shapes with no defined geometry. That was the problem. The engineers tried treating them as parabolas, then circular ribs, then ellipsoids, at least 12 versions in all. Every curve was different, so every piece of concrete would have needed its own custom mould, and casting the shells in place would have cost a fortune.
The breakthrough came in 1961. If all the shells were slices of one sphere, they would all share the same curvature. Arches of different lengths could then be cast in a common mould, and identical segments could be lined up side by side. A factory on site produced 2,400 precast ribs and 4,000 roof panels, and even the tiles could be fixed in sheets on the ground rather than one by one high up. Designing it also involved one of the earliest uses of computers in structural analysis.
The building still went ten years over schedule and 1,357% over budget. Utzon left the project in 1966 after a clash with the government, and he died in 2008 without ever returning to see it finished.
1,357%
Quiz me
0/3
Recap
Same sphere, same curve, same mould: that's how the sails went from sketch to concrete.
Surprising fact · Utzon resigned in 1966 and died in 2008 without ever returning to see the finished building.
